Description
Fusion Apollo MS-AP12000 Amplifier Monoblock 650 Watts RMS
Fusion Apollo MS-AP12000 Monoblock Marine Amplifier (650-watt RMS)
Model: 010-02284-10- Keep the music going for longer without draining your battery as quickly.
- No more manual adjustments to your audio settings. The Easy Tune feature does it for you2.
- A glance at the LED indicators lets you identify if the amplifiers have a short or if they’re overheating.
- These amps have less distortion and noise, so you enjoy quality audio.
- Mounting brackets are included for simple installation.
- Don’t worry about potential overheating damage with our ignition protection design.
Don’t worry about potential overheating damage with our ignition protection design.
These amplifiers use the Easy Tune feature2, which automatically regulates audio settings. So, you can get the best quality sound without making manual adjustments.
Some amplifiers distort audio when they add power. Ours are specifically designed with minimal distortion and noise, so you can enjoy high-quality audio, even at higher volumes.
Identify electrical issues at a glance. These indicator lights will show you issues with electrical currents and shorts as well as temperature.
Easily install the amplifiers on board with the included mounting brackets.
Easily install the amplifiers on board with the included mounting brackets.
The amplifier’s circuit board has been specially coated to provide extra protection from the marine elements.
You can connect up to two speakers per channel, increasing setup options.
The amplifiers are designed to last season after season. They have been tested to a high level of protection against salt fog, temperature, vibration and UV.
Add extra power to your system with this 2000-watt (650-watt RMS) monoblock amplifier that’s specifically designed to power a subwoofer.
1 Amplifiers are designed exclusively for use with Fusion DSP-enabled stereos (Apollo RA770, Apollo RA670, Apollo WB670 and RA210) and Fusion speakers
2 Requires setup using the Fusion-Link app on a compatible smartphone
Physical dimensions without bracket (LxWxH) 9.25" x 7.06" x 1.75" (235 x 180 x 45 mm)Physical dimensions with bracket (LxWxH)9.25" x 7.06" x 2.13" (235 x 180 x 50 mm)Weight4.85 lb (2.2 kg)Water RatingIPX2Amplifier classClass-DCEA-2006 power rating650 watt RMS x 1 @ 14.4 V input - 4 ohm < 1% THDTotal rated power output - 2 ohm (watts)1100 watt RMS x 1 @ 14.4 V input - 2 ohm < 1% THDTotal rated power output - 4 ohm Bridged (watts)NAPeak power (watts)2000 wattsInput sensitivity2 V RMSInput impedance22k ohmOperating voltage10.8 V - 16 V DCCurrent consumption (StandBy)< 5 mA @ 14.4 V inputCurrent consumption (Idle)< 0.89 A @ 14.4 V inputCurrent consumption (Max)87 AFuse rating125 A electronic fuse (no replacement necessary)Ignition Safety Protected (SAE J1171)YesProtection circuitsReverse voltage
Input under/over voltage
Over temperature
Output short circuitOperating temperature range32° to 122° F (0° to 50° C)
What's in the Box:
- One Apollo monoblock amplifier
- One mounting bracket
- One power connector
- One speaker connector
- Four 8-guage, flat head self-tapping screws
- Four 8-guage, pan head self-tapping screws (for mounting bracket)
- Four screw covers
- Mounting template
- Installation instructions
- Important safety and product information (ISPI)
